SS-T2Y-100-GRS, SS-T2Y-100-GR2

FlexRail Composite Guardrail Type 2

The FlexRail Composite Guardrail Type 2 attaches to SlowStop® bollards to create longitudinal barriers. The flexible material can withstand 110 kN of frontal force without any permanent deflection and will return to its original shape after impact. The FlexRail is recessed to allow overlapping of multiple lengths and its lightweight allows for easy installation; it can even be used to form curves (4m min. radius) without bending equipment.

FlexRail comes complete with hardware for attaching to SlowStop® bollards. Ideal for long aisles where expected accidents are brushing impacts.

End Caps attach to standard 2m sections of SlowStop® FlexRail to provide an end impact zone. Universal end caps are available to round off either end of a Flexrail run.

Specifications

  • Color: RAL 1023 Yellow
  • Material: Proprietary Composite
  • Dimensions: 100 cm (customizable x 2m per section)
  • Rail Break: Strength 110 kN
  • Impact Rating: Rail 17.000 joules; Post 10.200 joules
  • Temperature Rating: 5°C to 65°C
  • Flexible: No Bending Equipment Required for Curves
  • End Caps: Option Universal End Cap (75 mm overhang)
