SS-T3Y-68-HS-112, SS-T3Y-112-HS-112

IronFlex Horseshoe Bollard Type 3 – International

The horseshoe dual bollard consists of two Type 3 rebounding bollard bases with steel pipe and connectors to create a horseshoe bollard. This is ideally suited to protect your most critical equipment and the harshest environments. The Type 3 horseshoe is among the strongest surface mount guarding units available anywhere. Horseshoe bollards create twice the stopping power of a single Type 3 rebounding bollard.

The tall version can stop 10,000 kg at 9.2 kph, and the short version can stop 10,000 kg at 11.8 kph without damage. This unit will protect against accidental impacts without the need to constantly repair the bollard or re-pouring concrete foundations.

Installation is in less than an hour without the need to core existing concrete. The steel pipe is pre-cut and painted yellow, although the entire unit can be painted to match existing color schemes. Standard units are 68cm x 112cm (short) and 112cm x 112cm (tall). Custom lengths, colors, and striping options are available.

Specifications

  • Color: RAL 1023 Yellow Pipe on RAL 9005 Black Pedestal
  • Diameter: 177,8mm (6,3mm wall)
  • Height: 68cm to centerline; 112cm to centerline
  • Width: 112cm centers, 130cm outside uprights, 153cm overall footprints; 112cm centers, 130cm outside uprights, 153cm overall footprints
  • Impact Rating: Rail 65.000 joules, Post 26.700 joules; Rail 65.000 joules, Post 26.700 joules
  • Temperature Rating: -40°C - 70°C
  • Pipe Coating: EN-ISO 1461 Galvanized + Polyester Powder Coating
  • Cast-Iron Coating: Environmentally Friendly Water-based KTL Coating + Polyester Powder Coating. C5I corrosion resistance.
  • Set Screws: M16 x 2,00 – 8mm Hex
  • Anchor Screws: Sixteen (16) M16x140 Concrete
